SKU: EL_00009
Category: Power IC
Uses: Typical applications are mobile phones and similar battery-powered wireless systems, portable information
appliances.

FEATURES

. Input voltage from 2.5 V to 6 V
. Logic-controlled electronic shutdown
. Very low dropout voltage (at 300 mA load)
. Very low quiescent current
. Internal current and thermal limit
. Stable with low ESR ceramic capacitors
. Guaranteed output current up to 300 mA

The LDS3985 provides up to 300 mA, from 2.5 V to 6 V input voltage. It Smaller device size (as neither large inductors nor transformers are needed). It is stable with ceramic and high quality tantalum capacitor.And greater design simplicity . The ultra low drop voltage, low quiescent current and low noise make it suitable for low power applications and battery-powered systems. Usually consists of a reference, an amplifier, and a pass element.Shutdown logic control function is available, this means that when the device is used as local regulator, it is possible to put a part of the board in standby, decreasing the total power consumption. Typical applications are mobile phones and similar battery-powered wireless systems, portable information appliances.
